- Vertical and horizontal wave motion
- Displays for temperature, speed/tilt angle, and time
- Timer with audible alarm
- 5 year manufacturer warranty
The Talboys Professional 1000WS Incubating Waving Shaker combines the unique vertical and horizontal "wave" motion with general purpose incubation in one compact bench top unit.
Operating Features:
Microprocessor Control: The microprocessor control provides electronic tilt angle adjustment which allows user to easily adjust waving angle from 0 to 20° while unit is operating. Precise speed control provides smooth, low-speed waving motion down to 1rpm.
PID Temperature Controller: Maintains precise temperature control from ambient +5°C to 65°C. Easy to use controls allow users to adjust temperature in 1°C increments.
Trip Eccentric Drive: Permanently lubricated ball bearings and maintenance free, brushless DC motor provide reliable service and continuous duty operation.
LED Display: Touch pad controls with easy-to-read, independent LED displays for temperature, speed/tilt angle, and time allow operator to view all settings at once. Provides repeatable and accurate results every time and is easily visible across lab benches. Timer will display elapsed time or when programmed to user defined limit, will shut off unit when time reaches zero. Display will show last used settings, even after power has been turned off.
Safety Features:
Overload Protection: Audible and visual signals will activate when system detects an obstruction or overload of the tray.
Ramping Feature: Slowly increases speed to desired set-point to avoid splashing.
Audible Alarm: In timed mode, alarm will sound when the time reaches zero.
Caution Hot Indicator: Symbol illuminates when the temperature of the air in the chamber reaches 40°C and remains lit until temperature cools down.
Spill-Resistant Design: Channels fluids away from internal components.
Polycarbonate Lid: Permits viewing of samples without disturbing internal temperature.
Operating Comditions:
Unit can be run from 5 to 40°C (41 to 104°F).
Applications:
Cell cultures, hybridization procedures, and blotting techniques.
| Temperature Range | Ambient +5°C to 65°C |
| Temperature Uniformity | ±0.5°C at 37°C |
| Speed Range | 1 to 30rpm* |
| Speed Accuracy | ±1rpm |
| Tilt Angle | 0 to 20°* |
| Timer | 1 second to 160 hours |
| Maximum Weight Capacity | 5lbs (2.3kg)** |
| Tray Material | Aluminum |
| Tray Dimensions (L x W) | 9.25 x 7.25"
(23.5 x 18.4cm) |
| Interior Dimensions | 10.75 x 7.75 x 3.4" |
| (L x W x H) | (27.3 x 19.7 x 8.6cm) |
| Overall Dimensions | 17 x 11 x 10.5" |
| (L x W x H) | (43.2 x 27.9 x 27cm) |
| Ship Weight | 22lbs (10kg) |
* Maximum speed/tilt angle may vary with heavy or unbalanced loads.
** Centered on tray.
